Glass Lifter GL-850
Compact telescoping mast lifter — 660 lb, 28 ft reach, with glass attachments
About the Glass Lifter GL-850
The GL-850 is a compact and versatile material lifter designed for vertical and overhead glazing, construction sites, and workshops. With a telescoping aluminum mast reaching 28 ft (8.5 m) and a 660 lb (300 kg) load capacity, it folds quickly for single-operator setup and transport. Available in two power configurations: the DC version includes a rechargeable battery and charger for cord-free operation, while the AC version runs from a standard outlet. Operates via remote control with anti-fall safety system on the mast. Optional glass holder, universal cradle, and crane arm attachments transform the GL-850 from a general material lifter into a dedicated glass installation tool. Ideal for storefront glazing, curtain wall, and overhead glass installation.
Key Features
- 660 lb (300 kg) maximum load capacity
- 28 ft (8.5 m) maximum lift height
- Telescoping aluminum mast (strong, light, compact when stowed)
- Available in DC (battery) or AC (corded) versions
- Remote control operation; operator stays clear of the load
- Anti-fall safety system on mast + auto-safety kill switch
- Adjustable legs for setup on uneven surfaces
- Quick folding base, single-operator setup
- Optional glass holder, universal cradle, and crane arm attachments
Application & Technical Notes
Indoor Clearance
- Folded height 2.15 m (7 ft) — fits through standard commercial doorways and freight elevators
- Full mast extension requires minimum 9 m (30 ft) overhead clearance
- Adjustable legs allow setup on uneven surfaces without shims
Glass Attachment Notes
- Glass holder attachment rated for panels up to 300 kg (660 lb)
- Compatible with Low-E, tempered, laminated, and insulated glass units (IGUs)
- Universal cradle attachment converts the GL-850 for non-glass overhead work
Power & Runtime
- DC version: full-day operation on a single charge for typical lift cycles
- AC version: unlimited runtime from standard 110V outlet
- Remote control range: up to 15 m (50 ft) line of sight
Technical Specifications
Downloads & Resources
Have a question about the Glass Lifter GL-850?
Our team responds the same day. Get specs, pricing, or expert advice.
